Float Type: Aqua 2400
Floats
Float Total Weight: 390 lbs
Float Total Length: 18ft
Engine, Fuel Injection: Lycoming IO-540-W1A5D
Propeller, Hartzel Constant Speed, 2 Blade: 81inch
Wing Span: 30ft 11inches
Length: 23ft 6inches
Height: 9.7ft
Cabin Width: 1.07m
Confguration: 5 place
Gross Weight: 2750lbs
Empty Weight: 1772lbs
Useful
Load: 897lbs
Fuel Capacity: 73gals
Stall Speed (Full flaps, Power Off): 40mph
Take Off Roll water: less than 900ft
Take Off at Gross over 50ft Obstacle: 1200ft
Rate of Climb: 1300fpm
Landing Roll Water: less than 500ft
Landing Distance Water at max Gross over 50ft Obstacle: less than 900ft
Best Climb Speed: 90mph
Service Ceiling: 17 000ft
Fuel Consumption (75% power): 11gph
Range: 815/889mi
Speed Max: 135kts
Cruise (75% power opt. alt.): 124kts
Flap Settings: -7, 0, 24, 40°
|
